| Brand Name: | SMX |
| Model Number: | MX-X20000U |
| MOQ: | 1pc |
| Packaging Details: | Carton |
| Payment Terms: | T/T |
20K Lumen 3D Mapping Building Projector 20000 Lumen Highest Brightness LCD Laser Projector for Outdoor Large Venue Immersive Projection
The SMX MX-X20000U offers high brightness, high contrast and high color reproduction with the new 3LCD and laser light optical engine. The MX-X20000U is equipped with a full suite of optional motorized lenses and advance keystone correction. It enables realistic image reproduction, even in bright projection environment.
Explore a whole new realm of immersive projection and choose this 20,000 lumen LCD laser projector to revolutionize your visual experience. With excellent brightness and a contrast ratio of up to 3,000,000:1, this projector delivers vivid, clear images in all lighting conditions, ensuring that every detail comes to life.
Whether it is a large-scale performance, an immersive exhibition display, or 3D Mapping, this projector can easily handle it and bring the ultimate immersion. Its advanced laser light source technology not only extends the service life, but also reduces maintenance costs, ensuring that you can still enjoy stable performance during long-term use.
Combined with flexible mounting options and rich connectivity, this projector can meet a variety of application needs and is your ideal choice for creative display and efficient communication. Choose this high-performance projector to make every presentation an unforgettable audio-visual feast!
Specification
| Model | MX-X20000U | |
| Brightness | ||
| Brightness(Lumen) | 20,000 | |
| Overall Spec | ||
| Panel | Display Panel | 3x1.0" |
| Display Technology | Liquid Crystal Display | |
| Native Resolution | WUXGA (1920 x 1200) | |
| Laser Lifetime | Normal mode | 20000hrs |
| ECO mode | 30000hrs | |
| Projection Lens (STD) |
Len Model | MX-EG12ZLM |
| Zoom/Focus | Motorized | |
| Throw Ratio (16:10) | 1.24-2.01 @100inch | |
| F | 1.8-2.24 | |
| f | 27.7-44.3mm | |
| Zoom Ratio | 1.62 | |
| Screen size | 60-500 inch | |
| Lens Shift V | ±65% | |
| Lens Shift H | ±25% | |
| CR | Contrast Ratio(Min) | 3,000,000:1 |
| Noise | Noise(dB) | Full:46db / Normal:44db / Eco1:43db / Eco2:42db |
| Uniformity | Uniformity | TYP:90% |
| AR | Aspect Ratio | Native:16:10 Compatible: 4:3/16:9/normal/16:6 |
| Terminal(I/O port) | ||
| Input | VGA | *1 |
| HDMI 1.4(IN) | *2 | |
| USB-A | *1 | |
| USB-B | *1 (Display) | |
| RJ45 | *1 (Display) | |
| DVI-D | *1 | |
| HD BaseT | *1 | |
| Audio in(mini jack,3.5mm) | *1 (VGA/DVI-D share) | |
| DMX512 | *1 | |
| Output | HDMI 1.4(OUT) | *1 |
| Audio out (mini-jack,3.5mm) | *1 | |
| Control | RS232C (Input) | *1 |
| RS232C (Output) | *1 | |
| Wired Remote(IN) | *1 | |
| Wired Remote(OUT) | *1 | |
| Other Functions | ||
| Keystone | Keystone Correction | V: ±30° H:±30° Pincushion/Barrel Correction 6 Corner Geometry correction Grid ImageTune correction |
| OSD | Languages | 26 languages: English, German, French, Italian, Spanish, Polish, Swedish, Dutch, Portuguese, Japanese, Simplified Chinese, Traditional Chinese, Korean, Russian, Arabic, Turkish, Finnish, Norwegian, Danish, Indonesian, Hungarian, Czech, Kazak, Vietnamese, Thai, Farsi |
| LAN Control | LAN Control-RoomView (Crestron) | Yes |
| LAN Control-AMX Discovery | Yes | |
| LAN Control-PJ Link | Yes | |
| Display Resolution | Computer Signal Input | VGA, SVGA, XGA, SXGA,WXGA,UXGA,WUXGA,4K@30Hz |
| Others | 360° projection | 360° Install |
| Edge Blending | Yes | |
| Adjustable brightness | Yes | |
| Dimension&Weight | ||
| Product Size (WxHxD mm) | 599X240.2X493.8mm (not including lens) | |
| Net. Weight (KG) | 28.9Kg (not including lens) | |
| Accessory | ||
| Manual Languages | Chinese, English | |
| Standard Accessories | Power cord (3m, Black), Remote control | |
WUXGA Resolution(1920*1200)
Lens Shift
High Contrast
Edge Blending Function
20000 Hours Laser Light Source
Multiple Ports
Specification
| Model | MX-X20000U | |
| Brightness | ||
| Brightness(Lumen) | 20,000 | |
| Overall Spec | ||
| Panel | Display Panel | 3x1.0" |
| Display Technology | Liquid Crystal Display | |
| Native Resolution | WUXGA (1920 x 1200) | |
| Laser Lifetime | Normal mode | 20000hrs |
| ECO mode | 30000hrs | |
| Projection Lens (STD) |
Len Model | MX-EG12ZLM |
| Zoom/Focus | Motorized | |
| Throw Ratio (16:10) | 1.24-2.01 @100inch | |
| F | 1.8-2.24 | |
| f | 27.7-44.3mm | |
| Zoom Ratio | 1.62 | |
| Screen size | 60-500 inch | |
| Lens Shift V | ±65% | |
| Lens Shift H | ±25% | |
| CR | Contrast Ratio(Min) | 3,000,000:1 |
| Noise | Noise(dB) | Full:46db / Normal:44db / Eco1:43db / Eco2:42db |
| Uniformity | Uniformity | TYP:90% |
| AR | Aspect Ratio | Native:16:10 Compatible: 4:3/16:9/normal/16:6 |
| Terminal(I/O port) | ||
| Input | VGA | *1 |
| HDMI 1.4(IN) | *2 | |
| USB-A | *1 | |
| USB-B | *1 (Display) | |
| RJ45 | *1 (Display) | |
| DVI-D | *1 | |
| HD BaseT | *1 | |
| Audio in(mini jack,3.5mm) | *1 (VGA/DVI-D share) | |
| DMX512 | *1 | |
| Output | HDMI 1.4(OUT) | *1 |
| Audio out (mini-jack,3.5mm) | *1 | |
| Control | RS232C (Input) | *1 |
| RS232C (Output) | *1 | |
| Wired Remote(IN) | *1 | |
| Wired Remote(OUT) | *1 | |
| Other Functions | ||
| Keystone | Keystone Correction | V: ±30° H:±30° Pincushion/Barrel Correction 6 Corner Geometry correction Grid ImageTune correction |
| OSD | Languages | 26 languages: English, German, French, Italian, Spanish, Polish, Swedish, Dutch, Portuguese, Japanese, Simplified Chinese, Traditional Chinese, Korean, Russian, Arabic, Turkish, Finnish, Norwegian, Danish, Indonesian, Hungarian, Czech, Kazak, Vietnamese, Thai, Farsi |
| LAN Control | LAN Control-RoomView (Crestron) | Yes |
| LAN Control-AMX Discovery | Yes | |
| LAN Control-PJ Link | Yes | |
| Display Resolution | Computer Signal Input | VGA, SVGA, XGA, SXGA,WXGA,UXGA,WUXGA,4K@30Hz |
| Others | 360° projection | 360° Install |
| Edge Blending | Yes | |
| Adjustable brightness | Yes | |
| Dimension&Weight | ||
| Product Size (WxHxD mm) | 599X240.2X493.8mm (not including lens) | |
| Net. Weight (KG) | 28.9Kg (not including lens) | |
| Accessory | ||
| Manual Languages | Chinese, English | |
| Standard Accessories | Power cord (3m, Black), Remote control | |
Video
Video
Video
|
| Brand Name: | SMX |
| Model Number: | MX-X20000U |
| MOQ: | 1pc |
| Packaging Details: | Carton |
| Payment Terms: | T/T |
20K Lumen 3D Mapping Building Projector 20000 Lumen Highest Brightness LCD Laser Projector for Outdoor Large Venue Immersive Projection
The SMX MX-X20000U offers high brightness, high contrast and high color reproduction with the new 3LCD and laser light optical engine. The MX-X20000U is equipped with a full suite of optional motorized lenses and advance keystone correction. It enables realistic image reproduction, even in bright projection environment.
Explore a whole new realm of immersive projection and choose this 20,000 lumen LCD laser projector to revolutionize your visual experience. With excellent brightness and a contrast ratio of up to 3,000,000:1, this projector delivers vivid, clear images in all lighting conditions, ensuring that every detail comes to life.
Whether it is a large-scale performance, an immersive exhibition display, or 3D Mapping, this projector can easily handle it and bring the ultimate immersion. Its advanced laser light source technology not only extends the service life, but also reduces maintenance costs, ensuring that you can still enjoy stable performance during long-term use.
Combined with flexible mounting options and rich connectivity, this projector can meet a variety of application needs and is your ideal choice for creative display and efficient communication. Choose this high-performance projector to make every presentation an unforgettable audio-visual feast!
Specification
| Model | MX-X20000U | |
| Brightness | ||
| Brightness(Lumen) | 20,000 | |
| Overall Spec | ||
| Panel | Display Panel | 3x1.0" |
| Display Technology | Liquid Crystal Display | |
| Native Resolution | WUXGA (1920 x 1200) | |
| Laser Lifetime | Normal mode | 20000hrs |
| ECO mode | 30000hrs | |
| Projection Lens (STD) |
Len Model | MX-EG12ZLM |
| Zoom/Focus | Motorized | |
| Throw Ratio (16:10) | 1.24-2.01 @100inch | |
| F | 1.8-2.24 | |
| f | 27.7-44.3mm | |
| Zoom Ratio | 1.62 | |
| Screen size | 60-500 inch | |
| Lens Shift V | ±65% | |
| Lens Shift H | ±25% | |
| CR | Contrast Ratio(Min) | 3,000,000:1 |
| Noise | Noise(dB) | Full:46db / Normal:44db / Eco1:43db / Eco2:42db |
| Uniformity | Uniformity | TYP:90% |
| AR | Aspect Ratio | Native:16:10 Compatible: 4:3/16:9/normal/16:6 |
| Terminal(I/O port) | ||
| Input | VGA | *1 |
| HDMI 1.4(IN) | *2 | |
| USB-A | *1 | |
| USB-B | *1 (Display) | |
| RJ45 | *1 (Display) | |
| DVI-D | *1 | |
| HD BaseT | *1 | |
| Audio in(mini jack,3.5mm) | *1 (VGA/DVI-D share) | |
| DMX512 | *1 | |
| Output | HDMI 1.4(OUT) | *1 |
| Audio out (mini-jack,3.5mm) | *1 | |
| Control | RS232C (Input) | *1 |
| RS232C (Output) | *1 | |
| Wired Remote(IN) | *1 | |
| Wired Remote(OUT) | *1 | |
| Other Functions | ||
| Keystone | Keystone Correction | V: ±30° H:±30° Pincushion/Barrel Correction 6 Corner Geometry correction Grid ImageTune correction |
| OSD | Languages | 26 languages: English, German, French, Italian, Spanish, Polish, Swedish, Dutch, Portuguese, Japanese, Simplified Chinese, Traditional Chinese, Korean, Russian, Arabic, Turkish, Finnish, Norwegian, Danish, Indonesian, Hungarian, Czech, Kazak, Vietnamese, Thai, Farsi |
| LAN Control | LAN Control-RoomView (Crestron) | Yes |
| LAN Control-AMX Discovery | Yes | |
| LAN Control-PJ Link | Yes | |
| Display Resolution | Computer Signal Input | VGA, SVGA, XGA, SXGA,WXGA,UXGA,WUXGA,4K@30Hz |
| Others | 360° projection | 360° Install |
| Edge Blending | Yes | |
| Adjustable brightness | Yes | |
| Dimension&Weight | ||
| Product Size (WxHxD mm) | 599X240.2X493.8mm (not including lens) | |
| Net. Weight (KG) | 28.9Kg (not including lens) | |
| Accessory | ||
| Manual Languages | Chinese, English | |
| Standard Accessories | Power cord (3m, Black), Remote control | |
WUXGA Resolution(1920*1200)
Lens Shift
High Contrast
Edge Blending Function
20000 Hours Laser Light Source
Multiple Ports
Specification
| Model | MX-X20000U | |
| Brightness | ||
| Brightness(Lumen) | 20,000 | |
| Overall Spec | ||
| Panel | Display Panel | 3x1.0" |
| Display Technology | Liquid Crystal Display | |
| Native Resolution | WUXGA (1920 x 1200) | |
| Laser Lifetime | Normal mode | 20000hrs |
| ECO mode | 30000hrs | |
| Projection Lens (STD) |
Len Model | MX-EG12ZLM |
| Zoom/Focus | Motorized | |
| Throw Ratio (16:10) | 1.24-2.01 @100inch | |
| F | 1.8-2.24 | |
| f | 27.7-44.3mm | |
| Zoom Ratio | 1.62 | |
| Screen size | 60-500 inch | |
| Lens Shift V | ±65% | |
| Lens Shift H | ±25% | |
| CR | Contrast Ratio(Min) | 3,000,000:1 |
| Noise | Noise(dB) | Full:46db / Normal:44db / Eco1:43db / Eco2:42db |
| Uniformity | Uniformity | TYP:90% |
| AR | Aspect Ratio | Native:16:10 Compatible: 4:3/16:9/normal/16:6 |
| Terminal(I/O port) | ||
| Input | VGA | *1 |
| HDMI 1.4(IN) | *2 | |
| USB-A | *1 | |
| USB-B | *1 (Display) | |
| RJ45 | *1 (Display) | |
| DVI-D | *1 | |
| HD BaseT | *1 | |
| Audio in(mini jack,3.5mm) | *1 (VGA/DVI-D share) | |
| DMX512 | *1 | |
| Output | HDMI 1.4(OUT) | *1 |
| Audio out (mini-jack,3.5mm) | *1 | |
| Control | RS232C (Input) | *1 |
| RS232C (Output) | *1 | |
| Wired Remote(IN) | *1 | |
| Wired Remote(OUT) | *1 | |
| Other Functions | ||
| Keystone | Keystone Correction | V: ±30° H:±30° Pincushion/Barrel Correction 6 Corner Geometry correction Grid ImageTune correction |
| OSD | Languages | 26 languages: English, German, French, Italian, Spanish, Polish, Swedish, Dutch, Portuguese, Japanese, Simplified Chinese, Traditional Chinese, Korean, Russian, Arabic, Turkish, Finnish, Norwegian, Danish, Indonesian, Hungarian, Czech, Kazak, Vietnamese, Thai, Farsi |
| LAN Control | LAN Control-RoomView (Crestron) | Yes |
| LAN Control-AMX Discovery | Yes | |
| LAN Control-PJ Link | Yes | |
| Display Resolution | Computer Signal Input | VGA, SVGA, XGA, SXGA,WXGA,UXGA,WUXGA,4K@30Hz |
| Others | 360° projection | 360° Install |
| Edge Blending | Yes | |
| Adjustable brightness | Yes | |
| Dimension&Weight | ||
| Product Size (WxHxD mm) | 599X240.2X493.8mm (not including lens) | |
| Net. Weight (KG) | 28.9Kg (not including lens) | |
| Accessory | ||
| Manual Languages | Chinese, English | |
| Standard Accessories | Power cord (3m, Black), Remote control | |
Video
Video
Video
