| Brand Name: | SMX |
| Model Number: | MX-VL780U |
| MOQ: | 1Pc |
| Price: | 2417usd/pc |
| Packaging Details: | Carton Package |
| Payment Terms: | T/T |
Long Throw LCD Laser Projector MX-VL780U 7800 Lumen 3LCD Laser Projector
The SMX MX-VL780U is a high brightness laser projector with 7800 lumens. It is suitable for business, education and public spaces. It has a life span of 20, 000 hours, and is capable of projecting an ultra large screen with a WUXGA resolution of up to 300 inches. Equipped with lens shift, 1.6x optical zoom, advanced keystone correction and 360 degree projection, the MX-VL780U projector offers flexible setup options.
Key Features:
Keystone Correction
The SMX's MX-VL780U features horizontal & vertical keystone correction, hexagonal correction, pincushion/barrel distortion correction, and multi-point keystone correction. Easy adjustment ensures users get the best imaging effect on all kinds of irregular projection surfaces.
WUXGA(1920*1200) Resolution
WUXGA offers a higher vertical resolution than 1080p (1920 x 1080), allowing for greater detail, especially in text and graphics.
High Contrast 5000000:1
High contrast projectors can better reproduce vivid colors, making images look more vivid and realistic. The differences in colors are more obvious, improving the viewing experience.
LAN Control Efficiency Function
It is compatible with Crestron, PJ Link, and AMX Discovery, allowing for more efficiency and flexibility in device management.
Ultra-long Laser Light Life Time 20000 Hours
360° Flexible Installation
Allows the projector to be rotated freely (360°) in order to point up or down depending on the installation requirements.
Edge blending Function
This function seamlessly blends multiple projected images to display a single high-resolution image.
Lens Shift
Vertical and horizontal lens shift enables flexible projector placement.
Specification
| Model No. | MX-VL780U | |
| Brightness(Lumen) | 7800 | |
| Resolution | WUXGA | |
| Light source | LASER | |
| Overall Spec | ||
| Panel | Display Technology | Liquid Crystal Display |
| Native Resolution | WUXGA (1920 x 1200) | |
| Light source Life time | Full Normal/Normal mode | 20000hrs |
| ECO1 mode | 30000hrs | |
| ECO2 mode | 30000hrs | |
| Projection Lens | F | 1.58-2.02 |
| f | 15.3mm-24.6mm | |
| Zoom/Focus | Manual | |
| Throw Ratio | 1.08 (wide)-1.76 (tele) | |
| Zoom Ratio | 1.6 | |
| Screen size | 30-300 inch | |
| Lens Shift | V:＋45%～0%, H:±21% |
|
| CR | Contrast Ratio (FOFO) |
5000000:1 |
| Noise | Noise(dB) *1 | 39dB(Normal) 31dB(ECO1) 29dB(ECO2) |
| Uniformity | Uniformity(Actual Min) -JISX6911 |
80% |
| AR | Aspect Ratio | Native:16:10 Compatible: 4:3/16:9 |
| Terminal(I/O port) | ||
| Input | VGA | *1 |
| HDMI 1.4B(IN) | *2 | |
| USB-A | *1 | |
| USB-B | *1 (Display) | |
| RJ45 | *1 (Display) | |
| HD BaseT | *1(Optional) | |
| Audio in (mini jack,3.5mm) |
*1 | |
| Output | VGA | *1 |
| Audio out (mini-jack,3.5mm) |
*1 | |
| Control | RS232 | *1 |
| RJ45 | *1 (Control) | |
| USB-B | *1 (For upgrade) | |
| General Spec | ||
| Audio | Speaker | 16W*1 |
| Dust filter | W/Filter | |
| Filter Life time | 8000h | |
| Power Consumption | Power Requeirements | 100~240V@ 50/60Hz |
| Power Consumption (Normal) (Max) |
425 | |
| Power Consumption (ECO1) (Max) |
285 | |
| Power Consumption (ECO2) (Max) |
235 | |
| ECO Standby Mode Power Consumption |
<0.5W | |
| Temp.&Humidity | Operating Temp. | 0m≤Altitude≤1700m, Ambient 0°C~50°C |
| 1700m＜Altitude＜3000m, Ambient 0°C~40°C |
||
| Operating humidity. | 20-85% | |
| Store Temp. | -10 to 50°C | |
| High altitude | 0~3000m | |
| Other Functions | ||
| Keystone | Keystone Correction (Lens@center) |
V: ±30° H:±30° Pincushion/Barrel Correction 6 Corner Geometry correction 4 Corner Correction Grid image tune |
| OSD | Languages | 26 languages: English, German, French, Italian, Spanish, Polish, Swedish, Dutch ,Portugese, Japanese, Simplified Chinese, Traditional Chinese, Korean, Russian, Arabic, Turkish, Finnish, Norwegian, Danish, Indonesian, Hungarian, Czech, Kazak,Vietnamese,Thai, Farsi |
| LAN Control | LAN Control-RoomView (Crestron) |
Yes |
| LAN Control--AMX Discovery | Yes | |
| LAN Control--PJ Link | Yes | |
| Display Resolution | Computer Signal Input | VGA, SVGA, XGA, SXGA,WXGA,UXGA,WUXGA,4K@30Hz |
| Video Signal Input | 480i, 480p, 576i, 576p, 720p, 1080i and 1080p | |
| SW setting | Auto Setup | INPUT SEARCH,AUTO PC,Auto Keystone |
| Blank | Yes | |
| Suspend | Yes(5 minutes no signal as default) | |
| Picture mode | Dynamic,Standard,Cinema, Colorboard,sim-DICOM,Blackboard(Green) |
|
| Cooling time | 0s,normal,30s | |
| Auto Ceiling | Yes | |
| D-Zoom | 1~33 | |
| Others | 360° projection | Yes |
| Edge Blending | Yes | |
| Dimension&Weight | ||
| Product Size (mm) | 405 (W)*358(D)*137(H) | |
| Net. Weight (KG) | ~7.9KG | |
| Accessory | ||
| Manual Languages | Chinese,English | |
| Standard Accessaries | Power cord, HDMI cable,Remote control | |
